Quantium Fuel Dispenser

Diesel Fuel dispenser for industrial purposes; approved for Class C fuels and for non-commercial use.

Main features:

• Corrosion-resistant stainless steel chassis and painted panels.
• Compact rotary vane suction pump, cast iron body, equipped with inline filter, air eliminator and internal by-pass valve.
• Available in the following flow rates: 50 lpm, 80 lpm, 130 lpm.
• 1 Hp motor.
• Three phases, 400V/50 Hz motor (pump) or single-phase 230V power supply.
• Four-piston meter, consisting of a sleeved body in which four pistons drive two connecting rods, guaranteeing enhanced reliability.
• Accuracy: +/-0.2%.
• Electronic head with calculator or mechanical register.
• LCD display with backlight.
• High precision pulser, ready to be connected with a fuel management system.
• ZVA automatic fuel nozzle.
• 4 m antistatic flexible rubber hose.
• EEXD- ATEX certified motor in compliance with European Directive Atex 94/9/CE.
• EC certified and approved for Class C fuels
